Wire EDM Machine with Linear Motor

1. Liquid tank motor lifting

2. Linear motor control technology

3. Ultra low molybdenum wire loss

4. 150000mm ² No wire loss, more environmentally friendly

5. (Cutting condition: 9000 mm ²/ H | water-based cutting fluid | steel | workpiece height 60mm)

6. Maximum cutting efficiency: exceeding 300 mm ²/ Min or above

7. Optimal surface roughness: Ra ≤ 0.5 μ M

8. Optimal machining accuracy: ± 3um (absolute size)

9. Slow filament level UV axis structure

10. Five axis full servo control

11. Integrated structure of the entire machine

12. Support G code programming

13. Using Molybdenum Wire to Process Workpieces

1. Castings of the same grade in the Swiss machine tool industry, C-type structure (HT250)

2. The X-Y axis uses Taiwan HIWIN P-grade guide rails

3. X and Y axis without screw structure, using linear motor structure, long-term use without loss (customized by Hanqi)

4. The U-V axis uses Taiwan HIWIN C3 level lead screw guide rail

5. The X, Y, U, and V axes are controlled by servo motors (Panasonic motors and drivers)

6. The Z-axis is also controlled by a servo motor (Hanqi customized motor and driver)

7. Automatic lubrication system for screw guide rail (automatic lubrication pump)

8. Patented liquid tank lifting structure (customized by Hanqi)

9. ± 12 ° taper cutting structure

10. Anti rust and anti-corrosion workbench (customized by Hanqi)

11. The Windows 7 system is equipped with a CNC system independently developed by Hanqi

12. Integrated industrial control computer (customized by Hanqi)

13. The computer operation station can rotate 90 ° for easy operation

14. Embedded LED tricolor light (unique design, longer lifespan)

15. Integrated design of the main electrical cabinet and water tank (with a smaller footprint)

16. Hanqi's independently developed discharge machining circuit

1) The chairman has worked at Hanchuan Machine Tool Factory in China (1986-2005), focusing on the field of electrical machining for nearly 40 years;

2) The company was established in 2005, with its factory located in Suzhou High tech Zone, China, covering an area of 20000 meters ²;

3) It is a high-tech enterprise in Jiangsu Province and a specialized, refined, and innovative enterprise in Jiangsu Province;

4) With over 80 employees and nearly 20 research and development personnel, it is a research and development production oriented enterprise;

5) Implement the ISO9001 quality management system and use the Carl Zeiss three coordinate system for precision testing of machine tool components;

6)In 2016, we engaged in product cooperation with Beijing Agie Charmilles Industrial Electronics Co., Ltd;

What is EDM Machining?

Electrical discharge machining, EDM, is a manufacturing process where material is removed from a workpiece using a rapid sequence of electrical current discharges between electrodes submerged in a dielectric liquid. The process is used to manufacture parts that are impossible to machine. Since EDM does not use mechanical force to remove material, it is considered to be non-traditional.

EDM is an exceptionally precise process that is ideal for forming complex and intricate shapes and is capable of shaping hard metals such as titanium. The materials shaped using EDM must be electrically conductive for the process to be successful.

The workpiece electrode, anode, of an EDM machine is connected to the positive terminal of a DC power supply while the tool electrode, cathode, is connected to the negative terminal. The electrodes are submerged in the dielectric fluid and separated by the spark gap. Sparking generates extreme electrothermal heat in the spark gap zone, which melts and vaporizes parts of the workpiece surface, a process known as spark erosion.

The EDM wire machining process, an alternative to sinker EDM machining, works much like a wood band saw using a wire for the cutting process. The wire, made of copper or brass, has a high voltage electrical discharge passed through it that makes it possible for the wire to cut through the thickness of the workpiece.

The wire in EDM wire machining creates a spark in deionized water where conductivity is precision controlled. The water cools the material and washes away the removed material with clean dielectric fluid being constantly pumped into the process to flush the excess waste away.

The extreme temperatures of the EDM process rapidly removes excess material from the workpiece by vaporization and melting or spark erosion. The molten metal is partially removed. As the electric potential is withdrawn, the plasma channel is no longer sustained and generates pressure or shock waves as it collapses. This evacuates the molten material forming a crater of material that is removed from around the spark site.

Material is removed by the formation of shock waves as the plasma channel collapses due to electric potential discontinuation where the work material is made positive and the tool negative. As the electrons strike the workpiece, craters are formed by the heating, melting, and removal of material as positive ions strike the tool resulting in tool wear.

Electrical discharge machining requires a great deal of power. Generators used for the process must be capable of supplying the necessary power in order for the process to run efficiently and successfully. They are selected in accordance with their ability to generate the power parameters of the process.

EDM (DIE SINKER)/WIRE EDM machine tools are widely used in various industries, such as Digital home appliances, automotive manufacturing, medical equipment, semiconductor packaging, mold industry, aerospace, aluminum industry, bathroom fixtures, military manufacturing, etc

SUZHOU HANQI CNC EQUIPMENT CO.,LTD. was established in 2005, specializing in the production and customization of various precision CNC electric discharge machines(EDM) and CNC wire EDM cutting machines(WEDM) for over 30 years. Machine tool castings, same as Swiss brand, have undergone all major component inspections using German Zeiss coordinate tester and have collaborated with Swiss technology to ensure the precision and stability of EDM machines. Hanqi CNC machines(EDM/WEDM) are widely used in various industries, including mold manufacturing, automotive manufacturing, chip technology, medical equipment, electronics, electrical, hardware, plastics, etc. Hanqi CNC has cooperated with several world-renowned brands, including THK, Philips, Siemens, Panasonic, HIWIN, PMI, NSK, BYD, GCL, Chint, MIDEA, Mitsubishi Electric, GREE, GIANT, Zhongwang, FAGOR, FUJI, SAIC GM, CATL, Konka, Galanz, LUXSHARE ICT, Foxconn, FANUC,KNUTH etc. Our factory has relevant international authoritative certifications such as ISO9001, IS014001, CE, UL, ETL, etc. Our products have high cost-effectiveness and have been exported to more than 30 countries and regions around the world. With high-quality and high-precision machine tools (Industry leading in MS-WEDM/EDM machining accuracy), we can process very complex components and have been favored by customers from various countries, thus accumulating a large number of high-quality domestic and foreign long-term cooperative customers.
